summary
Item
P3
Chip
Epstar
Chip size
Red 9 mil, Green 12. Blue 12mil
Light type
SMD2121
Pixel Pitch
3mm
Module Size
192mmX192mm
Module Resolution
64 X 64 (dots)
Density of pixel
111111dots/m2
Pixel configuration
1R1G1B
Red wavelength
625±2nm
Green wavelength
525±2nm
Blue wavelength
470±2nm
Colors
16777216
Best viewing distance
≥2m
viewing angle
120°/90°
Maximum power consumption
20W
Brightness
1500cd/m2
Gray scale
14bits per color
Color temperature
6500k
Control method
Synchronization or Asynchronization
Driving method
1/32 scanning
Frame frequency
60Hz
Refresh frequency
≥600Hz
Working Voltage
DC5V
IP grade
IP54
MTBF
More than 8000hours
Life Span
80,000hours
