This is a nice metal 315MHz remote wireless keyfob with high electromagnetic conversion, strong emission power and low power consumption. It use SAW as frequency stabilizer and has a 6.5G UHF triode. The tiny and luxurious metal body will make you even cooler.
315M wireless modules are widely used in areas like vehicle monitoring, remote control, home security system, wireless meter reading, guard monitor system, industrial data acquisition system, wireless tag, identification, non-contact RF card, small wireless data terminals, fire safety systems, wireless remote control system, biological signal acquisition, hydrological/meteorological monitoring, robot control and so on.
Click here to know more about this product.
To use with 315MHz RF Receiver
.
Specification
Working voltage: 12V(27A battery)
Working current: ≤10mA
Oscillation mode: SAW resonance
Working frequency: 315MHz
Modulation mode: ASK
Frequency error: ±3kHz(max)
Emission power: 10mW
Code chip: SC2260-R4
Address codes: floating
Matching resistor: 12M
Transmission distance: <40 meters(open space)
Operating temperature: 0~+70 ℃
